Technical Specifications

•

  OS

  Android 9.x

•

  CPU

  High performance ARM Octa-Core A53 + Secure processor

•

  Memory

  2GB RAM, 16GB FLASH
  (Optional) MicroSD card(up to 128GB)

•

  Main Display

  10.1-inch IPS full color LCD display,
  resolution of 800 x 1280, capacitive multi-touch screen

•

  Secondary Display(Optional)

  10.1-inch IPS full color LCD display,
  resolution of 1280 x 800, capacitive multi-touch screen

•

  Wired communication

  Ethernet 10/100 Base-T

•

  Wireless Communication

  WIFI ( 802.11 b/g/n); Bluetooth 4.2
  (Optional) 4G

•

  Positioning

  GPS, GLONASS, BEIDOU

•

  Facial Recognition

  Structured light 3D camera, capable of liveness detection
  Support Facial Recognition Payment and 1D/2D code payment

•

  1D/2D Code Scanner(Optional)

  Profession scan engine, support 1D/2D code payment

•

  Audio

  1 x Speaker, 1 x Microphone, support audio recording and media play

•

  Keypad

  Virtual keypad,
  1 x function key,
  1 x power button

•

  Peripheral Ports

  1 x Micro USB, 2 x USB-A (Host), 1 x USB-A (HID), 1 x RS232,1 x Ethernet, 1 x DC Jack

•

  Power Supply

  Input: 100-240 V AC 50/60 Hz, 0.7A
  Output: 12V/2.5A

•

  Accessories(Optional)

  PCI 5.x certified secure PIN Pad, support PIN entry
  PCI 5.x certified secure PIN Pad with Mag-stripe / Chip / Contactless card acceptance

•

  Dimensions

  Desktop: 175mm(L) x 205mm(W) x 405mm(H)
  Poling: 170mm(L) x 200mm(W) x 610mm(H)
  Wall-hanging: 155mm(L) x 40mm(W) x 270mm(H)
  Dual Screen: 240mm(L) x 250mm(W) x 330mm(H)

•

  Weight

  Desktop: 2kg
  Poling: 3kg
  Wall-hanging: 800g
  Dual Screen: 3.38kg

•

  Environment

  Operating temperature: 0℃～40℃ (32℉~104℉)
  Storage temperature: -20℃～60℃ (-4℉~140℉)
  Relative humidity: 5%～93% (Non-condensing)

•

  Installation Methods

  Desktop, poling or wall-hanging
