Technical Specifications

•

  OS

  Android 5.x/7.x

•

  CPU

  32-bit ARM Cortex A7 Quad-Core, 1.1GHz+Secure processor

•

  Memory

  1GB RAM, 8GB FLASH.
  (Optional)2GB RAM, 16GB FLASH

•

  Display

  5-inch TFT full color LCD display, resolution of 1280x720.
  Capacitive multi-touch screen, supports electronic signature

•

  Wireless Communication

  4G / 3G / 2G,
  WIFI (802.11 b/g/n),
  Bluetooth 2.1/4.1

•

  Positioning

  GPS, GLONASS, BEIDOU

•

  Contactless Card Reader

  Conforming to ISO 14443 Type A/B(Optional)

•

  Camera

  0.3 MP front camera, support 1D/2D code paymen(Optional).
  5 MP autofocus rear camera with flashlight, support 1D/2D code payment

•

  Audio

  1x Speaker, 1 x Microphone, support audio recording and media play

•

  Keypad

  Secure virtual keypad for PIN entry,
  1 power button,
  1x function key

•

  Printer

  High-speed thermal printer, 32lps.
  Paper roll diameter: 40mm.
  Paper width: 58mm

•

  Peripheral Ports

  1 x Micro USB (OTG)

•

  Card Slots

  1 x SIM
  1 x SAM
  1 x Micro SD

•

  Battery

  Li-ion battery, 7.2V/2600mAh/18.7Wh (Equal to 3.6V/5200mAh)

•

  Power Supply

  Input: 100-240V AC 50/60Hz,0.2A
  Output: 5.0V DC, 1.0A

•

  Docking Station

  Charging base(Optional)

•

  Dimensions

  188mm (L) x 81mm (W) x 57mm (H)

•

  Weight

  410g including battery

•

  Environment

  Operating temperature: 0°C～40°C (32°F~104°F)
  Storage temperature: -20°C～60°C (-4°F~140°F)
  Relative humidity: 5%～93% (Non-condensing)
