Technical Specifications

•

  OS

  Android 10.x

•

  CPU

  64-bit ARM Cortex A53 Octa-Core, 1.8GHz

•

  Memory

  2GB RAM, 16GB Flash
  4GB RAM, 64GB FLASH (Optional)

•

  SD Card Slot

  MicroSD card (up to 256GB)

•

  Main Display

  15.6-inch TFT full color LCD display,
  resolution of 1920 x 1080,
  capacitive multi-touch screen

•

  Customer Display (Optional)

  10.1/15.6-inch TFT full color LCD display, resolution of 1280 x 800 / 1920 x 1080, capacitive multi-touch screen

•

  Wired Communication

  Ethernet 10/100 Base T

•

  Wireless Communication

  WIFI (802.11 a/b/g/n/ac) 2.4GHz & 5GHZ,
  Bluetooth 4.2
  4G/3G/2G (Optional)

•

  Positioning (Optional)

  GPS, GLONASS, BEIDOU

•

  Camera (Optional)

  5MP autofocus camera, support 1D/2D code payment

•

  Audio

  1 x Speaker, 1 x Microphone, support audio recording and media play

•

  Keypad

  Virtual keypad, 1 x power button, 2 x function keys

•

  Printer (Optional)

  High-speed thermal printer with cut paper automatically, 150mm/s
  Paper roll diameter: 80mm
  Paper roll width: 80mm

•

  Peripheral Ports

  4xUSB-A , 1xPinpad, 1x RS232, 1xMicroUSB, 1x DC Jack, 1xCashdrawer, 1x Ethernet, 1xHeadphone Port

•

  Power Supply

  Input: 100~240VAC 50/60Hz
  Output: 24.0VDC, 2.5A

•

  Dimensions

  380mm (L) x 234mm (W) x 328mm (H)

•

  Weight

  6.0kg with customer display
  5.2kg without customer display

•

  Environment

  Operating temperature: 0℃～40℃ (32℉~104℉)
  Storage temperature: -20℃～60℃ (-4℉~140℉)
  Relative humidity: 5%～95% (Non-condensing)
