Technical Specifications

•

  OS

  Android 14

•

  Processor

  Quad-core Cortex A73，2.4GHz + Quad-core Cortex A53，1.9GHz

•

  Memory

  4GB LPDDR4X+ 64GB eMMC
  8GB LPDDR4X+128GB eMMC (Optional)
  MicroSD card slot up to 512GB

•

  Main Display

  15.6 inch IPS (1920x1080)
  Capacitive touch screen

•

  Customer Display

  8 inch IPS (1280 x 800), Capacitive touch screen (X700 Payment Tablet) (Optional)

•

  Wired Communication

  RJ45-Ethernet 10/100M/1000M

•

  Wireless Communication

  Wi-Fi (802.11 a/b/g/n/ac) 2.4GHz&5GHz
  Bluetooth 2.1 + EDR/ 3.0/ 4.1 LE/ 4.2 BLE/ 5.0 LE
  4G/ 3G/ 2G

•

  Positioning

  GPS/GLONASS/BDS/Galileo

•

  Camera

  Front Camera FF 2MP
  FF 5MP (Optional)
  FF 8MP (Optional)

•

  Fingerprint

  MOH 80*64

•

  Audio

  Speaker 2W*2, Microphone *2

•

  Keypad

  Virtual keypad; Power button*1

•

  Peripheral Ports

  RJ12*1(Cash Drawer);
  USB TYPE A*4(USB 2.0*3+USB 3.0*1);
  USB TYPE C*3(Power+USB 3.0*1+USB 2.0*1);
  Pogopin *3(2*8pin USB 3.0*1+1*8pin USB 2.0*2)

•

  Card Slots

  Nano SIM *2
  Micro SD *1 (Can only hold 2 cards)
  eSim*1 (Optional)

•

  Power Supply

  Input: 100-240V AC 50/60Hz;
  Output: 20V, 3.25A

•

  Dimensions

  368.5mm (L) x 199mm (W) x 271mm (H)

•

  Weight

  2550g

•

  Environment

  Operating temperature: -10°C~50°C (14°F~122°F)
  Storage temperature: -20°C~60°C (-4°F~140°F)
  Relative humidity: 5% ~95% (Non-condensing)

  Charging below 0℃ is not recommended as it will affect battery performance.

•

  Certifications

  GMS, FCC, CE, CB, ROHS, EN18031

  Please contact Newland NPT sales representative for the latest certification status.
