N950S

Portable Android SmartPOS

A cost-effective solution that enables merchants
to process digital payment anywhere,
anytime, and anyway.



More Business Opportunities with Android 12

Running on Android 12, N950S can unlock more opportunities for merchants.

Cashless Experience at Anywhere, Anytime, and in Anyway

N950S supports multi-communication ways of 4G, 3G, GPRS, Bluetooth and Wi-Fi. lt enables merchant to accept payments via cards, mobile wallets and QR code, never compromising customer' payment preference.

Powerful Processing

High Speed Processor
ARM Quad-core cortex A53
Boosted Memory
Up to 2GB RAM 16GB FLASH

High Level Security Compliance of PCI PTS 6

Use-case Scenarios

Restaurants丨Malls丨Hotels丨Airports丨Stadiums





Technical Specifications

OS
Android 12
Processor
AP: Cortex Quad-core A53, 1.4GHz
SP: Cortex-M3 security core, 192MHz
Memory
1GB RAM, 8GB FLASH
2GB RAM, 16GB FLASH(Optional)
MicroSD card slot up to 128GB
Display
5-inch TFT full color LCD display, resolution of 854 x 480,capacitive multi-touch screen, support electronic signature
5-inch TFT full color LCD display, resolution of 1280 x 720,capacitive multi-touch screen, support electronic signature(Optional)
Wireless communication
4G / 3G / 2G
Wi-Fi 2.4GHz (802.11b/g/n); Bluetooth 4.2
Wi-Fi 2.4GHz&5GHz (802.11a/b/g/n/ac); Bluetooth 5.0(Optional)
Positioning
GPS, BEIDOU, GLONASS
Card Reader
Magnetic Card Reader,
Smart Card Reader,
Contactless Card Reader
Camera
0.3 MP front camera, support 1D/2D code payment(Optional)
2MP back camera, support 1D/2D code payment
5MP back camera, support 1D/2D code payment(Optional)
Audio
1 x Speaker, 1 x Microphone, support audio recording and media play
Keypad
Secure virtual keypad for PIN entry, 1 x power button, 1 x VOL+, 1 x VOL-
Printer
High-speed thermal printer, 80mm/s
Paper roll diameter: 40mm
Paper width: 58mm
Peripheral Ports
1 x Type C port
Card Slots
2 SIM +1 SAM + 1 SD
1 SIM +2 SAM + 1 SD(Optional)
1 SIM + 1 eSIM + 2 SAM + 1 SD(Optional)
Battery
Li-ion battery, 7.2V/2600mAh/18.7Wh (Equal to 3.6V/5200mAh)
Power Supply
Input: 100-240V AC 50/60Hz
Output: 5.0V DC, 2.0A
Dimensions
174mm (L) x 78mm (W) x 62mm (H)
Weight
380g including battery
Environment
Operating temperature: -10℃～50℃ (14℉~122℉)
Storage temperature: -20℃～60℃ (-4℉~140℉)
Relative humidity: 5%～93% (Non-condensing)
Certifications
PCI PTS 6.x, EMV L1/L2, EMV Contactless L1, PayPass, payWave, American ExpressPay,
Discover D-PAS, UnionPay QuickPass, TQM, CE, CB, RoHS, JCB, BIS, Rupay, VCCS
