Technical Specifications

•

  OS

  Android 7.1

•

  CPU

  32-bit ARM Cortex A7 Quad-Core, 1.1GHz + Cortex-M4 Secure Processor

•

  Memory

  1GB RAM, 8GB Nand Flash MicroSD card (Optional, up to 32GB)

•

  Display

  7-inch full color LCD display resolution of 1024*600 capacitive multi-touch screen

•

  Wireless Communication

  4G/3G/2G (Optional)
  WIFI (802.11 b/g/n), Bluetooth 2.1/4.1

•

  Wired communication

  Ethernet 10/100 Base T

•

  Card Reader

  Mag-stripe card,
  Chip card,
  NFC

•

  Camera

  0.3MP fixed focus front camera, support 1D/2D code payment

•

  Printer

  High-speed thermal printer, 80mm/s
  Paper roll diameter: 50mm
  Paper roll width: 58mm

•

  Peripheral Ports

  1 x DC Jack, 1 x Micro USB , compatible with USB2.0 HS standardand, 1 x USB-A, 1 x RS232, 1 x RJ45,1 x PINPAD, 1 x Cash drawer Interface

•

  Card Slots

  2 SAM
  1 SIM (Optional)

•

  Video

  Support 1080P video play and 720P video recording

•

  Audio

  1 x Speaker,
  1 x Microphone

•

  Power Supply

  Input: 100~240VAC 50/60Hz
  Output: 9.0VDC, 1.0A

•

  Dimensions

  188mm(L) x 115mm(W) x 160mm(H)

•

  Weight

  750g

•

  Environment

  Operating temp: 0℃～40℃
  Storage temp: -20℃～60℃
  Relative humidity: 5%～93% (Non-condensing)

•

  Certification

  PCI PTS 5.x, EMV L1/L2/CL1 PayPass, PayWave, RoHS, TQM, JCB, MCCS, Rupay, MIR
