P180

Retail PIN Pad

P180 is a Linux-based PIN pad to integrate with cash register to
process cashless payment efficiently. In addition to traditional
ways to accept payments made by cards or mobile phone,
P180 doesn’t fall out of trends regarding modern transaction
methods of QR code and HCE (Host Card Emulation) payment.



3.5-inch Touch Screen

The enlarged capacitive touch screen allows customer to make quick and smooth e-signature.

2MP Customer-facing Camera

Customers don’t need to hesitate when they want to pay with their QR code.

Host Card Emulation Supporting

P180-based HCE technology enables the merchant to not only process payment but also provide value-added service such as loyalty program and e-invoice.

Flexible Integration

Integrate P180 with cash register through ports of USB or
RS232, whichever the merchants need.

Multiple Communication Ways

Optional communication ways of WIFI and Ethernet are supported to suit certain use cases.

WIFI 2.4GHz/5GHZ
Ethernet 10/100M

Use-case Scenarios

Supermarket | Convenience stores | Grocery stores | Restaurants | Beverage





Technical Specifications

0S
Linux
Processor
Dual-core Cortex A7,
1GHz + Secure Processor
Memory
256MB RAM, 256MB FLASH
Micro SD (up to32GB)
Display
3.5-inch TFT full color LCD display,
resolution of 320 x 480
Capacitive touchscreen, support electronic signature
Card Reader
Magnetic Card Reader
Smart Card Reader
Contactless Card Reader
Audio
Speaker 1.5W(Optional)
Camera
2M pixels
Keypad
10 x numeric keys,
5 x function keys (Cancel(include ON/OFF )、Enter、backspace、*、#)
Back light
Card Slots
2 x SAM
Communication
RS232
USB Devise
Ethernet 10/100M(Optional)
WIFI 2.4GHz/5GHz(Optional)
Power Supply
Input: AC 100~240V Output: DC 5V-12V 5W
POE(Optional)
PUSB(Optional)
Accessories
Privacy Shield(Optional)
Kensington lock
Rotatable mount(Optional)
Customizable multifunction cable(Optional)
Dimensions
163mm (L) x 74mm (W) x 31mm (H) Without Privacy Shield
163mm (L) x 74mm (W) x 46mm (H) With Privacy Shield
Weight
NET weight 252g.
Gross weight 713g
Environment
Operating temperature: -10℃～50℃ (14℉~122℉)
Storage temperature:-20℃~70℃(-4°F~158°F)
Relative humidity: 5%～95% (Non-condensing)
Certifications
PCI PTS 6.x, EMV L1/L2, EMV Contactless L1, PayPass, payWave, American Expresspay, Discover D-PAS, AMEX, QuickPass, TQM, RoHS, CE, ANATEL, ABECS, MIR, FCC, JCB, UPTS 3.0
